Chemical transfer hose is specified from the inside out: the lining is chosen for the fluid, then the reinforcement for the pressure. Getting either wrong ends in a spill — and the lining decision is where most specification errors happen.
Lining Technology
- UHMWPE lining — ultra-high molecular weight polyethylene, the workhorse for a broad range of acids, alkalis and solvents at up to 80-90°C. Non-reactive, non-contaminating, and far cheaper than PTFE for large bores.
- PTFE lining — the ultimate barrier, for the most aggressive chemicals, higher temperatures, and duties where the product must not touch anything else. Smooth, non-stick, steam-cleanable.
- XLPE lining — cross-linked polyethylene, a cost-effective option for a defined range of chemicals at moderate temperatures.
Construction
Textile or spiral wire reinforcement gives working pressures from 10 to 20 bar with full vacuum service, and a tough EPDM or CR cover resists abrasion, weather and oil. Anti-static variants are available for flammable solvents.
Applications
- Chemical plants: acid and alkali transfer, tanker loading and unloading
- Pharma: solvent transfer in clean processes
- Marine and offshore: chemical offloading
- Manufacturing: process chemical dosing and transfer
Selection Support
Send us the chemical, concentration, temperature and working pressure. We check the compatibility against published resistance data and come back with a lining and construction recommendation — with the data sheet, not a guess.
FAQ
Can you supply chemical resistance data? Yes — compatibility tables for the lining, cover and fittings are provided with every quotation.
What about static discharge? Conductive UHMWPE and PTFE hoses are available for flammable fluids, with continuity through the fittings.
