PTFE (polytetrafluoroethylene) is the most chemically inert hose material in common industrial use. Nothing sticks to it, almost nothing attacks it, and it runs from cryogenic temperatures to 260°C continuous. The trade-off is mechanical: bare PTFE is limp, so it is reinforced with stainless steel braid and terminated with specially designed fittings.
Smooth Bore vs Convoluted
Smooth bore PTFE hose has a continuous, non-porous inner tube — the best choice where hygiene, low pressure drop and easy cleaning matter (pharma, food, high-purity chemicals). Convoluted (corrugated) PTFE hose is more flexible with a tighter bend radius, at the cost of a textured bore that can hold product.
SAE 100R14
The governing standard for PTFE hose with stainless steel reinforcement is SAE 100R14. It defines bore sizes, working pressures and bend radii so that hoses from different manufacturers are interchangeable in the same applications.
Typical Duties
- Steam: saturated steam to 200°C+, where rubber fails
- Chemicals: acids, solvents, oxidisers — anything aggressive
- Fuel and brake lines: conductive PTFE variants drain static
- Pharma and biotech: smooth bore, steam-cleanable, non-reactive
- Hot melt and adhesives: non-stick bore keeps product flowing
Options
Conductive (antistatic) inner tube for flammable fluids; covered (rubber overbraid) for abrasion resistance; pre-crimped assemblies with swaged fittings; custom lengths and end configurations.
FAQ
What is the temperature range? -60°C to 260°C continuous, with steam duties to 200°C+.
Is PTFE hose FDA compliant? Yes — PTFE is listed under FDA 21 CFR 177.1550 for food contact, and the smooth bore construction is CIP/SIP cleanable.
Do you supply assemblies? Yes — crimped assemblies with a choice of fittings, pressure tested before despatch.
